| VAN Code No. | 最小面取径 φd |
最大面取径 φd1 |
シャンク径 φD |
ルーマ長 l1 |
全長 L |
図 Fig. |
在庫 Stock |
参考価格 Price |
|---|---|---|---|---|---|---|---|---|
| 90SPC0.03X0.12CB | 0.03 | 0.12 | 3 | 0.4 | 40 | 3 | ● | ¥14,000 |
| 90SPC0.05X0.2CB | 0.05 | 0.2 | 3 | 0.6 | 40 | 3 | ● | ¥12,600 |
| 90SPC0.07X0.3CB | 0.07 | 0.3 | 3 | 0.9 | 40 | 3 | ● | ¥11,800 |
| 90SPC0.1X0.4CB | 0.1 | 0.4 | 3 | 1.2 | 40 | 3 | ● | ¥10,200 |
| 90SPC0.2X0.6CB | 0.2 | 0.6 | 3 | 1.8 | 40 | 3 | ● | ¥8,000 |
| 90SPC0.3X0.9CB | 0.3 | 0.9 | 3 | 2.7 | 40 | 3 | ● | ¥6,500 |
| 90SPC0.4X1.2CB | 0.4 | 1.2 | 3 | 3.6 | 40 | 3 | ● | ¥5,900 |
| 90SPC0.5X2X3CB | 0.5 | 2 | 3 | 6 | 40 | 3 | ● | ¥3,900 |
| 90SPC0.5X2CB | 0.5 | 2 | 40 | 2 | ● | ¥3,700 | ||
| 90SPC1.0X3SECB | 1 | 3 | 40 | 2 | ● | ¥3,400 | ||
| 90SPC1.0X3CB | 1 | 3 | 35 | 1 | ● | ¥6,700 | ||
| 90SPC1.5x4SECB | 1.5 | 4 | 40 | 2 | ● | ¥3,800 | ||
| 90SPC1.5X4CB | 1.5 | 4 | 40 | 1 | ● | ¥7,100 | ||
| 90SPC2.0X6SECB | 2 | 6 | 50 | 2 | ● | ¥5,200 | ||
| 90SPC2.0X6CB | 2 | 6 | 50 | 1 | ● | ¥9,600 | ||
| 90SPC2.5X8CB | 2.5 | 8 | 60 | 1 | ● | ¥13,000 | ||
| 90SPC3.0X10CB | 3 | 10 | 70 | 1 | ● | ¥18,200 | ||
| 90SPC4.0X12CB | 4 | 12 | 80 | 1 | ● | ¥22,500 | ||
| 90SPC5.0X16CB | 5 | 16 | 100 | 1 | ● | ¥34,000 | ||
| 90SPC6.0X20CB | 6 | 20 | 120 | 1 | ● | ¥54,000 |
Stock ● … 標準在庫品
被削材適合性
◎•••最適 ○•••適 △•••可 無印•••不可
| 製品区分 | 軟鋼 | 炭素鋼 | 合金鋼 | 調質鋼 | 工具鋼 | 焼入れ鋼 | ステンレス鋼 | |
|---|---|---|---|---|---|---|---|---|
| SS | S45C | SCM SCR |
SKD SKS |
～40 HRC |
～45 HRC |
45～ HRC |
SUS | |
| 60LSPC-CBALD | ○ | ○ | ◎ | ◎ | ○ | ◎ | ○ | ◎ |
| 90SPC-CB | ○ | ◎ | ◎ | ○ | ○ | ○ | △ | ◎ |
| 製品区分 | 鋳鉄 | タグタイル鋳鉄 | チタン合金 | アルミ合金 | 銅 | プラスチック | セラミックetc. | |
|---|---|---|---|---|---|---|---|---|
| FC | FDC | AI | Cu | マシナブル | ジルコニアガラス | |||
| 60LSPC-CBALD | ○ | ○ | ○ | |||||
| 90SPC-CB | ○ | ○ | ○ | ◎ | ○ | ○ | ○ | |
